Body: latest designed, convinient and user friendly 45° inclined stable body with epoxy finish paint.
Observation head: big binocular observation head with coated and well collimated prisms. Head inclined at 45° and 360° rotatable. It’s interpupillary distance 55 to 75mm with dioptric adjustment on left eye tube.
Nosepiece: advance quadrupple ball bearing revolving nose piece with positive click stops.
Focusing system: separate coarse and fine focusing knobs guided on balls.
Specimen stage: left hand side operated coaxial low drive and x-y movement mechanical stage 120 x 120 for holding the specimen slide.
Condenser: movable bright field abbe n.a 1.25 condenser (superior quality) with iris diaphgragm and filter holder can be move by rack and pinion knobs.
Light source: illumination fitted builtin base with 6v-20w halogen lamp with solid-state variable controlled transformer alongwith safety fuse.
Objectives: coated and antifungal-treated achromate objective: 4x/5x, 10x, 40x/45x (s.l), 100x oil (s.l). Our microscope’s objectives are well parafocalized to each other.
Eyepeices: strain-free and high eye point achromate w.f 10x coated eyepiece pair.
Accessories: vinyl dust cover, duster, cleaning brush, spare bulb and fuse with operating instruction manual in English.
Packing: complete microscope packed in export worthy styrofoam (thermocole) case packing.
