Approx. Size (Dia. X H):220mm x 230mm + 38mm Lid (9" x 11") – 1 KW Load
Approx. Capacity (Ltrs.): 10 Ltrs. With Lid
All autoclaves are constructed from heavy gauge aluminum. It’s generates steam under pressure and temperature between 120°C to 125°C.
Made from seamless Aluminium, top loading autoclaves. Seamless construction ensures bacteria free environment.
25-30 minutes sterilizing cycle at 121º c.
With two stages over pressure protection system incorporating a calibrated continuous bleeding pressure stopcock and pressure release weight valve.
With heat resistant handles and steam release / control valve.
Pressure Gauge : Colour coded pressure gauge showing internal chamber conditions during the cycle.
Sterilization zone in green colour is shown from 15 psi to 20 psi (OR 1.034 bar to 1.378 bar) which is equivalent to temperature of 121°c to 127°c.
Dial size : 2.5". Dial show measurement in 2 units (i) kg/cm² (ii) lb/inch². Full scale dial of pressure gauge is 0-30 lb/ inch² or 0-2 kg/ cm². Caution zone in red colour.
Supplied with inner & outer stand.
Suitable for 8"x8" Dressing/Sterilizing Drum
Optional : 1 Hr. Rotary Timer and Dressing/Sterilizing Drum in extra cost
Caution
DO NOT operate the autoclave without water and avoid using hard water
Close the lid properly and carefully, never attempt to open it during operation with force
Make sure that the rubber seal is in a good shape and condition
DO NOT use any alkaline solution in the unit
DO NOT put any extra weight on the stopcock
Clean and dry the unit after a day use.
