Main Features

• 12.1” Color TFT LCD display with waveforms upto 8 Channels.

• Portable, streamline handle design.

• Monitor measures from Adult and Neonates.

• Graphic and tabular trend for 96 hours for all parameters.

• Multi-Screen format.

• Audible and Visual Alarms with adjustable alarm ranges.

• Powerful data management and storage capacity.

• Manual or Automatic NIBP measuring.

• With 500unit memory.

• Rechargeable Battery Backup.

• Weight : 4.5 Kg. approx.


Respiration

• Method : RA-LL impedance

• Measurement Range : Adult : 0-120rpm, Paediatric Neonatal : 0-150rpm

• Apnea Alarm : Yes


Temperature

• Resolution : 0.1° C

• Channels : Dual – Channel

• Measurement Range : 0-50° C


IBP (Upgradable)

• Channel : 2 Channels

• Pressure Transducer : Sensitivity : 5 (mV V mmHg)

• Transducer Site : ART, PA, CVP, RAP, LAP, ICP

• Alarm Range : -10~300mmHg


ECG

• 5-lead or 12-lead selectable

• Input : 5-lead : RA; LA; RL; LL; V Or R; L; F; C

• Lead Selection : I; II; III; avR; avL; avF; Vx; CAL

• Gain Selection : x0.25, x0.5, x1, x2, auto

• Sweep Speed : 12.5mm/s, 25mm/s, 50mm/s

• Accuracy : +1bpm or +1%, whichever is greater

• Protection : Withstand 4000V AC/50Hz Voltage in isolation against electrosurgical and defibrillation

• Calibration Signal : 1mV=5%

• Operation Modes : Diagnostic, Monitor, Surgery

• Heart Rate Range : Adult : 15-300bpm Paediatric / Neonatal : 15-350bpm

• Measurement Range : -2.0mV ~ 2.0mV

• S-T Detection : Yes, Audible and Visual Alarm, Alarm events recallable


NIBP

• Method : Oscillometry

• Operation Modes : Manual Automatics / STAT

• Measurement Unit : mmHg / KPa selectable

• Measurement types : Systolic, Diastolic, Mean

• Measurement Range : Adult : 10-270mmHg

• Over-Pressure Protection : Yes

• Resolution : 1mmHg

• Accuracy : The mean error shall be less than ±5mmHg, the standard deviation shall be less than ±8mmHg

• Alarm : Systolic, Diastolic, Mean


SPO2

• Measurement Range : 0-100%

• Accuracy :±2% (70~100%); 0~69% Unspecified

• Alarm Range : 0-100%
