All autoclaves are constructed from heavy gauge aluminum. It’s generates steam under pressure and temperature between 120°C to 125°C.
Made from Seamless aluminum base with Cast Aluminum Epoxy powder coated Lid, top loading autoclaves. Locking of lid by 6 nuts with rubber gasket seal in between (no metal to metal seal). Seamless construction ensures bacteria free environment.
25-30 minutes sterilizing cycle at 121º C.
With two stages over pressure protection system incorporating a calibrated continuous bleeding Pressure stopcock and pressure release weight valve.
With heat resistant handles and with steam release /control valve and flexible metal exhaust tube.
Pressure Gauge : Colour coded pressure gauge showing internal chamber conditions during the cycle.
Sterilization zone in green colour is shown from 15 psi to 20 psi (or 1.034 bar to 1.378 bar) which is equivalent to temperature of 121°c to 127°c.
Dial size : 2.5". Dial show measurement in 2 units (i) kg/cm2 (ii) lb/inch2. Full scale dial of pressure gauge is 0-30 lb/ inch2 or 0-2 kg/cm2. Caution zone in red colour.
Supplied with inner and outer stand
Optional : 1 Hr. Rotary Timer and Sterilizing Drum in extra cost
DO NOT operate the autoclave without water and avoid using hard water
Close the lid properly and carefully, never attempt to open it during operation with force
Make sure that the rubber seal is in a good shape and condition
