Electrosurgical Unit (Diathermy Machine) 400 MATRIX+

Electrosurgical Unit (Diathermy Machine) 400 MATRIX+

Regular price Rs. 81,424.00
Regular price Sale price Rs. 81,424.00
Sale Sold out

Availability : In Stock

For Bulk Enquiry
Click on WhatsApp icon and write product Name with Quantity.
WhatsApp
WhatsApp or Call
098141-81255

Shipping & Returns

Free Shipping available on all orders!
We ship all India orders within 5-6 days.

Bulk Enquiries

WhatsApp or Call 9814262255 Click on WhatsApp icon and write product code with quantity.

View full details

PRODUCT DETAILS :

This is a 400-watt high power, operating room generator/ electrosurgical Unit. The unit consists tissue impedance monitoring system, self-adjustment of power output to reduce the continuous power setting for different tissue needs, to provide user consistent performance with all digital displays of power and modes. The system delivers 6 monopolar and bipolar RF energy modalities to provide a high level of surgical precision.

SPECIAL FEATURES :

  • A tissue sensing technology used for all applications to deliver user consistent performance.
  • Reduce the frequent adjustment of power setting as the tissue changes.
  • Reduce the risk of collateral tissue damage due to sparkles and charring free power.
  • Minimize the patient recovery time by performing precise and clean cutting and coagulation.
  • Minimum RF distortion in other O.T. Equipment.
  • Patient plate fault monitoring system.
  • The auto-monitoring facility displays different error codes if any error occurs during use.
  • Two independent power activation of monopolar output, hand switch operation, and footswitch operation.
  • Separate bipolar generator with foot switch operation or hand (auto) operation, eliminates the need of footswitch while using auto mode.


TECHNICAL SPECIFICATION :


Monopolar Cut
Watt (W)
Resistance (Ohm)
Crest Factor
Pure
400 W
500 Ohm
1.5
Blend
350 W
500 Ohm
Variable




Monopolar Coag



Soft
200 W
500 Ohm
1.5
Force
175 W
500 Ohm
Variable




Bipolar



Bi-Cut
150 W
100 Ohm

Micro
100 W
300 Ohm

TECHNICAL DATA

Input: 220/240 VAC / 50Hz

Power Consumption: 750 VA Max.

Protection Class: 1

MDD: IIB

Input Fuse: 6 AMP

Output Control: Digital Display

Nominal Frequency: MDD360Khz

Max. Output Power: 400 W

Basic Construction: IEC-60601-1, IEC-60601-1-2

Dimension: 390*130*340mm

Ambient Temperature: 30-40 Deg. C

Weight: 6.5 Kg.
